ﺍﻟﺴﺎﺩﺱﻋﺸﺮ ﻟﺘﻐﺬﻳﺔ ﺍﻟﻄﻮﺍﺑﻖ ﻣﻦ ﺍﻟﺴﺎﺩﺱﻋﺸﺮ ﺇﻟﻰ

ﺍﻟﻄﺎﺑﻖ ﺍﻟﺘﺎﺳﻊ .

8. ﻣﺠﻤﻮﻋــﺔ ﻣﻀﺨﺎﺕ ﻭﺍﻟﻔﻼﺗﺮ ﺍﻟﺨﺎﺻﺔ ﺑﻬﺎ ﻭﺳــﺨﺎﻧﺎﺕ ﺍﻟﻤﻴﺎﻩ

ﺍﻟﻤﺮﻛﺰﻳﺔ ﺑﻐﺮﻑ ﺍﻟﻤﻴﻜﺎﻧﻴﻚ ﺑﺴﻄﺢ ﺍﻟﻤﺒﻨﻰ ﺃﻋﻠﻰ ﺍﻟﻄﺎﺑﻖ

ﺍﻟﺜﺎﻣﻦ ﻟﺘﻐﺬﻳﺔ ﺍﻟﻄﻮﺍﺑﻖ ﻣﻦ ﺍﻟﺜﺎﻣﻦ ﻭﺣﺘﻰ ﺍﻟﺴــﺮﺩﺍﺏ ﺭﻗﻢ

. (3)

9. ﺃﻧﺎﺑﻴــﺐ ﺍﻟﻤﻴﺎﻩ ﻣﺼﻨﻮﻋﺔ ﻣﻦ ﻣﺎﺩﺓ ﺍﻟﺒﻮﻟــﻰ ﺑﻴﺘﻮﻟﻴﻦ ﺑﻄﻮﻝ

ﺇﺟﻤﺎﻟﻰ ) 00031 ( ﻣﺘﺮ ﻭﺗﺘﺮﺍﻭﺡ ﺃﻗﻄﺎﺭ ﺍﻟﻤﺤﺎﺑﺲﻣﻦ ) 52

( ﻣﻢ ﻭﺣﺘﻰ ) 051 ( ﻣﻢ .

01. ﻣﺠﻤﻮﻋﺎﺕ ﻣﻦ ﻣﺤﺎﺑﺲ ﺍﻟﻌﺰﻝ ﻟﻠﺘﺤﻜﻢ ﻓﻰ ﺃﺟﺰﺍﺀ ﺷــﺒﻜﺔ

ﺍﻟﻤﻴــﺎﻩ ﻭﺑﻌــﺪﺩ ﺇﺟﻤﺎﻟــﻰ )005( ﻣﺤﺒــﺲ ﻭﺗﺘــﺮﺍﻭﺡ ﺃﻗﻄﺎﺭ

ﺍﻟﻤﺤﺎﺑﺲ ﻣﻦ )52(ﻣﻢ ﺇﻟﻰ )051( ﻣﻢ .

2.2 ﺣﺊﺿﺎﺕ ﺍﻟﺧﺮﻑ ﺍﻟﺧﺗﻰ ﻭﺍﻓﻄﻄﺎﺭ :-

ﺗﺘﻜﻮﻥ ﺷﺒﻜﺎﺕ ﺍﻟﺼﺮﻑ ﺍﻟﺼﺤﻰ ﻭﺍﻷﻣﻄﺎﺭ ﻣﻦ ﺍﻟﻌﻨﺎﺻﺮ ﺍﻷﺗﻴﺔ:-

( HDPE )

1. ﺷﺒﻜﺔ ﻣﻦ ﺃﻧﺎﺑﻴﺐ

2. ﺟﻤﻴــﻊ ﺃﺟــﺰﺍﺀ ﺍﻟﻤﺒﻨﻰ ﻭﺣﺘﻰ ﻣﻨﺴــﻮﺏ ﺳــﻄﺢ ﺍﻷﺭﺽ ﻳﺘﻢ

( ﻭﺭﺑﻄﻬﺎ ﺑﺨﻄﻮﻁ

GRAVITY )

ﺻﺮﻓﻬــﺎ ﺑﻨﻈﺎﻡ ﺍﻟﺠﺎﺫﺑﻴﺔ

ﺍﻟﻤﺪﻳﻨﺔ .

3. ﺗــﻢ ﺗﻮﻓﻴــﺮ ﻧﻘﺎﻁﺻﺮﻑ ﻣﻴﺎﻩ ﺍﻷﻣﻄﺎﺭ ﻋﻠﻰﺳــﻄﺢ ﺍﻟﻤﺒﻨﻰ

ﻭﺟﻤﻴﻊ ﺍﻷﺟﺰﺍﺀ ﺍﻟﻤﻌﺮﺿﺔ ﻣﺒﺎﺷﺮﺓ ﻟﻤﻴﺎﻩ ﺍﻷﻣﻄﺎﺭ .

4. ﺗــﻢ ﻧﻮﻓﻴــﺮ ﻧﻘــﺎﻁ ﺻــﺮﻑ ﺃﺭﺿﻴــﺔ ﺑﺠﻤﻴــﻊ ﺩﻭﺭﺍﺕ ﺍﻟﻤﻴﺎﻩ

ﻭﺍﻟﻤﻄﺎﺑﺦ .

5. ﺗﻢ ﺗﻮﻓﻴﺮ ﻧﻘﺎﻁﺻﺮﻑ ﺃﺭﺿﻴﺔ ﺑﺴﺮﺍﺩﻳﺐ ﺍﻟﻤﺒﻨﻰ ﻣﻊ ﺭﺑﻄﻬﺎ

ﺑﻤﻀﺨﺎﺕ ﻏﺎﻃﺴــﺔ ﻳﺘﻢ ﺭﻓﻊ ﺍﻟﻤﻴﺎﻩ ﺇﻟﻰ ﻣﻨﺴــﻮﺏ ﺳــﻄﺢ

ﺍﻷﺭﺽ ﻭﺻﺮﻓﻬﺎ ﺇﻟﻰ ﺧﻂ ﺍﻟﻤﺪﻳﻨﺔ .

6. ﺃﻃــﻮﺍﻝ ﺃﻧﺎﺑﻴﺐ ﺍﻟﺼــﺮﻑ ﺍﻟﺼﺤﻰ ﻭﺍﻷﻣﻄــﺎﺭ )00021( ﻣﺘﺮ

ﻃﻮﻟﻰ ﻭﺗﺘﺮﺍﻭﺡ ﺍﻟﻘﻴﺎﺳﺎﺕ ﻣﻦ )05( ﻣﻢ ﻭﺣﺘﻰ )002( ﻣﻢ

7. ﻋﺪﺩ ﺍﻟﻘﻄﻊ ﺍﻟﺼﺤﻴﺔ ﺩﺍﺧﻞ ﺩﻭﺭﺍﺕ ﺍﻟﻤﻴﺎﻩ )008( ﻗﻄﻌﺔ .

3.2 ﺣﺊﺿﺋ ﺗﺶﺜﻏﺋ ﺍﻟﻌﺻﻌﺩ :-

ﺗﺘﻜﻮﻥ ﺷﺒﻜﺔ ﺗﻐﺬﻳﺔ ﺍﻟﻮﻗﻮﺩ ﻣﻦ ﺍﻟﻌﻨﺎﺻﺮ ﺍﻷﺗﻴﺔ :-

1. ﺧــﺰﺍﻥ ﻭﻗﻮﺩ ﺗﺤﺖ ﻣﺴــﺘﻮﻯ ﺳــﻄﺢ ﺍﻷﺭﺽ ﻳﺘﻢ ﻣﻦ ﺧﻼﻟﻪ

ﺗﻐﺬﻳــﺔ ﺧﺰﺍﻧﺎﺕ ﺍﻻﺳــﺘﺨﺪﺍﻡ ﺍﻟﻴﻮﻣﻰ ﺩﺍﺧــﻞ ﻏﺮﻑ ﻣﻮﻟﺪﺍﺕ

ﺍﻟﻜﻬﺮﺑﺎﺀ .

2. ﻣﺠﻤﻮﻋــﺔ ﻣﻦ ﺍﻷﻧﺎﺑﻴﺐ ﺗﺮﺑﻂ ﺑﻴﻦ ﺧﺰﺍﻧﺎﺕ ﺍﻟﻮﻗﻮﺩ ﻭﺧﺰﺍﻧﺎﺕ

ﺍﻻﺳﺘﺨﺪﺍﻡ ﺍﻟﻴﻮﻣﻰ .

3. ﻣﻀﺨــﺎﺕ ﺭﻓــﻊ ﻣﻦ ﺧــﺰﺍﻥ ﺍﻟﻮﻗﻮﺩ ﺍﻟﺮﺋﻴﺴــﻰ ﺇﻟــﻰ ﺧﺰﺍﻧﺎﺕ

ﺍﻟﻮﻗﻮﺩ ﺍﻟﻴﻮﻣﻰ .

4. ﺟﻤﻴــﻊ ﺃﻋﻤــﺎﻝ ﺍﻟﺘﻨﻔﻴــﺬ ﺳــﺘﺘﻢ ﻃﺒﻘــﺎﹰ ﻟﻤﻮﺍﺻﻔﺎﺕ ﺷــﺮﻛﺔ

( ﻭﺍﻹﺩﺍﺭﺓ ﺍﻟﻌﺎﻣﺔ ﻟﻺﻃﻔﺎﺀ )

KNPC )

ﺍﻟﺒﺘﺮﻭﻝ ﺍﻟﻮﻃﻨﻴﺔ

. ( KFC

2.4. ﺣﺊﺿﺋ ﻄﺿﺎﺸﺗﺋ ﺍﻟﺗﺮﻏﺺ :-

ﺗﺘﻜﻮﻥ ﺷﺒﻜﺔ ﻣﻜﺎﻓﺤﺔ ﺍﻟﺤﺮﻳﻖ ﻣﻦ ﺍﻟﻌﻨﺎﺻﺮ ﺍﻷﺗﻴﺔ :-

1. ﺧﺰﺍﻥ ﻣﻴﺎﻩ ﺍﻟﺤﺮﻳﻖ ﺑﺎﻟﺴﺮﺩﺍﺏ ﺭﻗﻢ )3(

2. ﺧﻂ ﺗﻐﺬﻳﺔ ﺍﻟﻤﺪﻳﻨﺔ ﻳﺘﻢ ﻣﻦ ﺧﻼﻟﻪ ﺗﻌﺒﺌﺔ ﺧﺰﺍﻥ ﺍﻟﺤﺮﻳﻖ.

3. ﺧﻂ ﺗﻐﺬﻳﺔ ﺍﻟﺘﻨﺎﻛﺮ.

4. ﻣﻀﺨﺎﺕ ﺍﻟﺤﺮﻳﻖ ﺍﻟﺮﺋﻴﺴﻴﺔ : ﻣﻀﺨﺔ ﺭﺋﻴﺴﻴﺔ ﺗﻌﻤﻞ ﺑﺴﻌﺔ

) 0001 ( ﺟﺎﻟﻮﻥ / ﺍﻟﺪﻗﻴﻘﺔ ﻭﺃﺧﺮﻯ ﺍﺣﺘﻴﺎﻃﻴﺔ .

5. ﻣﻀﺨﺔ ﺣﺮﻳﻖ ﻣﺴﺎﻋﺪﺓ ﺑﺴﻌﺔ )05( ﺟﺎﻟﻮﻥ / ﺍﻟﺪﻗﻴﻘﺔ .

6. ﺷﺒﻜﺔ ﻣﺮﺷﺎﺕ ﺗﻐﻄﻰ ﺟﻤﻴﻊ ﺃﺟﺰﺍﺀ ﺍﻟﻤﺒﻨﻰ .

7. ﻃﻮﻝ ﺃﻧﺎﺑﻴﺐﺷﺒﻜﺔ ﻣﻜﺎﻓﺤﺔ ﺍﻟﺤﺮﻳﻖ) 00586 ( ﻣﺘﺮ ﻭﺗﺘﺮﺍﻭﺡ

ﺃﻗﻄﺎﺭ ﺍﻷﻧﺎﺑﻴﺐ ﻣﻦ ﻗﻄﺮ) 52 ( ﻣﻢ ﻭﺣﺘﻰ ) 002 ( ﻣﻢ .

8. ﻋﺪﺩ ﻣﺮﺷﺎﺕ ﺷﺒﻜﺔ ﺍﻟﺤﺮﻳﻖ ) 00051 ( ﻣﺮﺵ .

9. ﻋﺪﺩ ﻓﻮﻫﺎﺕ ﺍﻟﺤﺮﻳﻖ ﺩﺍﺧﻞ ﺍﻟﻤﺒﻨﻰ ) 641 ( ﻓﻮﻫﺔ .

ﺍﻟﻤﺒﻨﻰ ﺍﻟﺮﺋﻴﺴﻲ ﻟﻠﻤﺸﺮﻭﻉ
